Illuminating a bridge at night can provide many benefits. It can improve the bridge's visibility for drivers, making it safer to cross. It can also make the bridge more visible to boats, helping to prevent collisions. In addition, bridge lighting can add a touch of beauty and drama to the structure, highlighting its unique features. There are many different ways to light a bridge, and each approach has its own advantages. Incandescent bulbs may provide the most natural-looking light, but LEDs are more energy-efficient and have a longer lifespan. One thing to consider when choosing a lighting scheme is the color of the light. White light may be the most functional, but colored lights can create a more festive atmosphere. No matter what approach you take, bridge lighting can add safety, elegance, and excitement to your structure.
- Brand: WareLight
- Wattage: 100W
- Lumens: 13,200
- CCT: 5000K
- Voltage: 120-277v
- LPW: 132 lp/w
- CRI: >80
- Dimmable: 1-10v
- Optic: Type 3 or Type 5
- Finish: Bronze
- Life: 50,000 hours
- Operating Temperature: -40° C to 45° C (-40° F to 104° F)
- Dimensions: 18.78"L x 13.11"W x 3.46"H
- Listings: cULus, IP65, DLC Premium
- 5 year warranty
- Brand: Westgate Manufacturing
- Wattage: 100
- Voltage: 120-277
- Lumens: 13500
- Color temperature: 5000K
- Color rendering index: >70
- Efficacy: 135 LPW
- Lifespan: 50,000 hrs.
- Listings: UL, DLC, IP65
- Warranty: 7 Years
- Brand: naturaLED
- Voltage: 100-277V
- Selectable Wattage: 20/28/34W or 60/80/100W
- Selectable CCT: 3000K/4000K/5000K
- CRI: 80
- Dimmable 1-10V
- Beam Angle: 110°
- Surge Protect Level: 4KV
- Mounting: Fits 2-3/8" Tenon
- Rated Life 50,000 Hours
- Built-in photocell sensor (turn on and off)
- Operating Temperature: -40°F ~ 122°F
- Ratings: DLC Premium, IP65, ETL, RoHS
- 5 Year Warranty
- Brand: Westgate Manufacturing
- Wattage Selectable: 50W/80W/100W/150W
- Voltage: 120-277
- CRI: >82
- Lumens: 8500-21400 (See Spec for Details)
- CCT: 3000K, 4000K, or 5000K
- Life: 70,000 hours
- 0-10V Dimmable
- Listings: IP65, UL, Wet Locations
- 7 year warranty
- Brand: WSD
- Wattage/Lumens Selectable:
- 60W / 9,305LM
- 80W / 12,059LM
- 100W / 14,585LM
- 150W / 20,030LM
- CCT Selectable: 3000K/4000K/5000K
- CRI: 70
- Operating Temperature: -40ºF ~ 104ºF
- 1-10V Dimming
- Life span: over 50,000 hrs
- Ratings: UL Listed, DLC Premium, Wet Location
- Warranty: 5 year limited
- Brand: LEDSION
- Wattage: 100
- Voltage: 120-277
- Lumens: 13000
- CCT: 5000K
- Life: 50,000 hours
- Listings: ETL, IP65, DLC
- Length: 13.6" without Yoke Mount, 15.8" with Yoke Mount
- Width: 11.6"
- 5 year warranty
- Mounting: Yoke Mount
- Finish: Bronze
- Brand: WareLight
- Wattage: 96W
- Voltage: 120-277
- Lumens: 13,479
- CCT Selectable: 3000K/4000K/5000K
- Mounting: Knuckle
- Photocell Option Available
- CRI: 70+
- UV stabilized powder coated finish.
- Solid construction die-cast aluminum body
- Ratings: cULus, DLC Premium
- 5 year warranty
- Brand: Envision
- Wattage Selectable/Lumens Selectable:
- 100W / 13,500LM
- 120W / 16,200LM
- 150W / 20,250LM
- CCT Selectable: 3000K/4000K/5000K
- Voltage: 120-277VV
- CRI: 80
- Average life (L70) of 50,000 hours
- Operating Temperature: - 40° - 122° F
- Non-dimmable
- Finish: Bronze, Black, White
- Ratings: UL Listed, DLC Listed, Wet Location, ROHS
- Warranty: 5 Year Limited Warranty
- Brand: Envision
- Wattage Selectable/Lumens Selectable:
- 60W / 8,100LM
- 80W / 10,800LM
- 100W / 13,500LM
- CCT Selectable: 3000K/4000K/5000K
- Voltage: 120-277VV
- CRI: 80
- Average life (L70) of 50,000 hours
- Operating Temperature: - 40° - 122° F
- Non-dimmable
- Finish: Bronze, Black, White
- Ratings: UL Listed, DLC Listed, Wet Location, ROHS
- Warranty: 5 Year Limited Warranty
- Brand: Etherium
- Wattage Selectable: 100W/150W/200W
- CCT Selectable: 3000K/4000K/5000K
- Lumens: 14000/21000/28000LM
- Voltage: 120V-277V
- CRI: 80
- Life: 75,000 hrs
- Dimmable: 0-10V
- Operating Temperature: -4°F to 113°F (-20°C to 45°C)
- Anti-UV Frosted Polycarbonate Lens standard.
- Call for Glare Shield Availability
- Ratings: DLC Premium listed, cULus Listed, Wet Location
- Warranty: 5 years
- Brand: WSD
- Wattage: 100W
- Lumens: 13210 Lm
- Voltage: 120-277V
- CCT: 5000K
- CRI: 70
- Dimming: 0-10V dimming
- Finish: Black
- Life: 75000 hours
- Listings: cULus, DLC Premium, RoHS, Wet Location
- 5 years warranty
- Brand: QSSI
- Wattage: 100
- Voltage: 120-277 or 347-480
- CCT: 3000K, 4000K or 5000K
- L70 Life (@25 C): 327,000 hours
- Distribution Options:
- Type II (12766 lumens @ 4000K)
- Type III (12817 lumens @ 4000K)
- Type IV (11881 lumens @ 4000K)
- Type V (12826 lumens @ 4000K)
- Listings: UL, IP66
- Replaces 150-250 watt HID
- Finish: Black
- Lens: Clear Polycarbonate Array
- 5 year warranty
- Brand: Westgate Manufacturing
- Wattage Selectable / Lumens:
- 50W / 6,500Lm
- 80W / 10,400Lm
- 100W / 13,000Lm
- Voltage: 120-277V
- CCT Selectable: 3000K/4000K/5000K
- Rated Life: 70,000hrs
- Dimming: 0-10V
- Operating Temperature: -40°F~104°F
- UL, IP66, Wet Locations
- Warranty: 7 Years
- Brand: Westgate Manufacturing
- Wattage Selectable / Lumens:
- 50W / 6,500Lm
- 80W / 10,400Lm
- 100W / 13,000Lm
- Voltage: 120-277V
- CCT Selectable: 3000K/4000K/5000K
- Rated Life: 70,000hrs
- Dimming: 0-10V
- Operating Temperature: -40°F~104°F
- UL, IP66, Wet Locations
- Warranty: 7 Years
- Brand: Westgate Manufacturing
- Wattage Selectable / Lumens:
- 80W / 10,400Lm
- 100W / 13,000Lm
- 150W / 19,500Lm
- Voltage: 120-277V
- CCT Selectable: 3000K/4000K/5000K
- Rated Life: 70,000hrs
- Dimming: 0-10V
- Operating Temperature: -40°F~104°F
- Made to Order
- UL, IP66, Wet Locations
- Warranty: 7 Years
- Brand: Atlas
- Wattage: 91W
- Voltage: 120-277V
- Lumens: 13,037 LM
- CCT Selectable: 3000K/4000K/5000K
- CRI: 70
- Lifespan: 50,000 hours
- Listings: CULUS Listed, DLC Premium Listed
- 5 year warranty
- Brand: Atlas
- Wattage: 37W/62W/84W
- Voltage: 120-277V
- Lumens: 12,007 Max
- CCT: 3000K/4000K/5000K
- CRI: 80
- Dimming: 0-10V
- Listings: CULUS Listed, DLC Premium Listed
- 5 year warranty
- Brand: Atlas
- Wattage: 62W/93W/127W
- Voltage: 120-277V or 347-480V
- Lumens: 16,487 Max
- CCT: 3000K/4000K/5000K
- CRI: 70
- Dimming: 0-10V
- Finish: Bronze
- Listings: CULUS Listed, DLC Premium Listed
- 5 year warranty
- Brand: Atlas
- Wattage: 62W/92W/126W
- Voltage: 120-277V or 347-480V
- Lumens: 18,184 Max
- CCT: 3000K/4000K/5000K
- CRI: 70
- Dimming: 0-10V
- Finish: Bronze
- Listings: CULUS Listed, DLC Listed
- 5 year warranty
- Brand: Eiko
- Voltage: 120-277V or 277-480V
- Wattage Selectable: 150/130/100W
- CCT Selectable: 3000/4000/5000K
- Lumens: 21,000/18,200/14,000 lm
- CRI: 80
- Distribution Types: Type 3 or 5
- Estimated L70: 100,000 Hours
- 0-10V dimming, dim-to-off
- Ratings: DLC Premium Listed, UL Listed, ROHS, IP65
- DLC ID #:
- 120-277V Type 3: S-HCIM8B
- 277-480V Type 3: S-YGKEH2
- 120-277V Type 5: S-W1RAHP
- 277-480V Type 5: S-E429BI
- Warranty: 5 years warranty
- Brand: Westgate Manufacturing
- Wattage Selectable: 80W/100W/150W/200W
- Lumens: 11200LM/14000LM/21000LM/28000LM
- CCT: 3000K or 5000K
- Voltage: 480V
- Lens Type: Optical TYPE III Lens
- CRI: 70
- Rated Life: 70,000 hrs
- Dimming: 0-10 Dimming
- Maximum Ambient Temperature: 104°F
- BUG: B3-U0-G3
- Ratings: UL Listed, Wet Location, IP65
- Warranty: 7 years warranty
- Brand: Westgate Manufacturing
- Wattage Selectable: 50W/80W/100W/150W
- Lumens: 7000LM/1120LM/14000LM/21000LM
- CCT: 3000K or 5000K
- Voltage: 480V
- Lens Type: Optical TYPE III Lens
- CRI: 70
- Rated Life: 70,000 hrs
- Dimming: 0-10 Dimming
- Maximum Ambient Temperature: 104°F
- BUG: B3-U0-G3
- Ratings: UL Listed, Wet Location, IP65
- Warranty: 7 years warranty
- Brand: Westgate Manufacturing
- Wattage Selectable: 80W/100W/150W/200W
- Lumens: 1120LM/14000LM/21000LM/28000LM
- CCT: 3000K or 5000K
- Voltage: 120-277V
- Lens Type: Optical TYPE III Lens
- CRI: 70
- Rated Life: 70,000 hrs
- Dimming: 0-10 Dimming
- Working Temperature: 104°F
- BUG: B3-U0-G3
- Ratings: UL Listed, Wet Location, IP65
- Warranty: 7 years warranty
- Brand: Westgate Manufacturing
- Wattage Selectable: 50W/80W/100W/150W
- Lumens: 7000LM/1120LM/14000LM/21000LM
- CCT Selectable: 3000K or 5000K
- Voltage: 120-277V
- Lens Type: Optical TYPE III Lens
- CRI: 70
- Rated Life: 70,000 hrs
- Dimming: 0-10 Dimming
- Working Temperature: 104°F
- BUG: B3-U0-G3
- Ratings: UL Listed, Wet Location, IP65
- Warranty: 7 years warranty
- Brand: LEDSION
- Wattage Selectable: 80W/100W/150W
- Lumens: 12000/13000/22500LM
- CCT Selectable: 3000K/4000K/5000K
- Voltage: 120-277V
- CRI: 80
- 50,000 hours lifetime
- 0-10V dimming
- Working Temperature: -20°C to 45°C
- BUG: B3-U0-G3
- Ratings: cULus Listed, DLC Premium, IP65
- Warranty: 5 years warranty
- Brand: Etherium
- Wattage Selectable: 100W/150W/200W
- CCT Selectable: 3000K/4000K/5000K
- Lumens: 14000/21000/28000 LM
- Voltage: 347-480V
- CRI: 80
- Life: 75,000 hrs
- Dimmable: 0-10V
- Operating Temperature: -4°F to 113°F (-20°C to 45°C)
- Anti-UV Frosted Polycarbonate Lens standard.
- Ratings: DLC Premium listed, cULus Listed, Wet Location
- Warranty: 5 years
- Brand: EnVision
- Wattage Selectable: 80W/120W/150W
- Lumens: 12,000/18000/22,500 LM
- CCT Selectable: 3000/4000/5000K
- Voltage: 277-480V
- CRI: 80
- Mount Options Available
- Operating Temperature: -40° - 122° F
- Average life (L70) of 70,000 hours
- Ratings: DLC, UL Listed, IP65
- Brand: EnVision
- Wattage Selectable: 80W/120W/150W
- Lumens: 12,000/18000/22,500 LM
- CCT Selectable: 3000/4000/5000K
- Voltage: 120-277V
- CRI: 80
- Mount Options Available
- Operating Temperature: -40° - 122° F
- Average life (L70) of 70,000 hours
- Ratings: DLC, UL Listed, IP65
LED Bridge Lighting Fixtures
Please call us for more information on Bridge Office Lighting.
