Illuminating a bridge at night can provide many benefits. It can improve the bridge's visibility for drivers, making it safer to cross. It can also make the bridge more visible to boats, helping to prevent collisions. In addition, bridge lighting can add a touch of beauty and drama to the structure, highlighting its unique features. There are many different ways to light a bridge, and each approach has its own advantages. Incandescent bulbs may provide the most natural-looking light, but LEDs are more energy-efficient and have a longer lifespan. One thing to consider when choosing a lighting scheme is the color of the light. White light may be the most functional, but colored lights can create a more festive atmosphere. No matter what approach you take, bridge lighting can add safety, elegance, and excitement to your structure.
- Brand: WareLight
- Wattage: 300W
- Lumens: 39,900
- CCT: 5000K
- Voltage: 120-277v
- LPW: 133 lp/w
- CRI: >80
- Dimmable: 1-10V
- Optic: Type 3 or Type 5
- Finish: Bronze
- Life: 50,000 hours
- Operating Temperature: -40° C to 45° C (-40° F to 104° F)
- Dimensions: 25.94"L x 13.11"W x 3.54"H
- Listings: cULus, IP65, DLC Premium
- 5 year warranty
- Brand: WareLight
- Wattage: 100W
- Lumens: 13,200
- CCT: 5000K
- Voltage: 120-277v
- LPW: 132 lp/w
- CRI: >80
- Dimmable: 1-10v
- Optic: Type 3 or Type 5
- Finish: Bronze
- Life: 50,000 hours
- Operating Temperature: -40° C to 45° C (-40° F to 104° F)
- Dimensions: 18.78"L x 13.11"W x 3.46"H
- Listings: cULus, IP65, DLC Premium
- 5 year warranty
- Brand: WareLight
- Wattage: 150W
- Lumens: 19,800
- CCT: 4000K
- Voltage: 120-277v
- LPW: 132 lp/w
- CRI: >80
- Dimmable:1-10V
- Optic: Type 3
- Finish: Bronze
- Life: 50,000 hours
- Operating Temperature: -40° C to 45° C (-40° F to 104° F)
- Dimensions: 18.78"L x 13.11"W x 3.46"H
- Listings: cULus, IP65, DLC Premium
- 5 year warranty
- Brand: WSD
- DLC Partner: Wisdom
- ID#: PZPW48N0
- Wattage: 400
- Voltage: 120-277
- Lumens: 56800
- CCT: 5000K
- CRI: >70
- Dimensions: L 25.53" x W 14.57" x H 3.16"
- Net Weight: 21.4 lbs
- 0-10V dimmable
- Life: 50,000 hours
- Listings: cULus, IP66, DLC Premium
- 5 year warranty
- Bronze Finish
- Brand: WareLight
- Wattage: 150W
- Lumens: 19,800
- CCT: 5000K
- Voltage: 120-277v
- LPW: 132 lp/w
- CRI: >80
- Dimmable: 1-10V
- Optic: Type 3 or Type 5
- Finish: Bronze
- Life: 50,000 hours
- Operating Temperature: -40° C to 45° C (-40° F to 104° F)
- Dimensions: 18.78" L x 13.11" W x 3.46" H
- Listings: cULus, IP65, DLC Premium
- 5 year warranty
- Brand: WSD
- DLC Partner: Wisdom
- ID#: P4PTJCKZ
- Wattage: 200W
- Voltage: 120-277V
- Lumens: 27,000
- CCT: 5000K
- CRI: >70
- Dimensions: L 24" x W 11.13" x H 6.3"
- Net Weight: 16.6 lbs
- 0-10V dimmable
- Life: 50,000 hours
- Listings: cULus, IP66, DLC Premium
- 5 year warranty
- Bronze Finish
- Brand: WareLight
- Wattage Selectable: 70W/100W/150W
- CCT Selectable: 3000K/4000K/5000K
- Lumen Max: 20,007
- Voltage: 120-277V
- Optics: Type II, III (Standard), IV, or V
- CRI: >70
- WareSense Blue Compatible
- Mounting Options: Universal (Standard), Slip Fitter, Pole and Yoke
- Lifespan: 50,000 hours
- Working Temperature: -40°C TO 45°C (-40°F TO 113°F)
- Dimensions:23.7"L x 9.8"W x 6.4"H
- DLC ID# S-LCF9Y5
- Ratings: cULus, DLC Premium, IP65
- Warranty: 5 year warranty
- Brand: WareLight
- Wattage Selectable: 200W/240W/300W
- CCT Selectable: 3000K/4000K/5000K
- Lumen Max: 43,360
- Voltage: 120-277V
- Optics: Type II, III, IV, or V
- CRI: >70
- WareSense Blue Compatible
- Mounting Options: Universal (Standard), Slip Fitter, Pole and Yoke
- Lifespan: 50,000 hrs
- Working Temperature: -40°C TO 45°C (-40°F TO 113°F)
- Dimensions: 30.5"L x13.3"W x 6.4"H
- DLC ID# S-V042DF
- Ratings: cULus, DLC Premium, IP65
- Warranty: 5 year warranty
- Brand: GKOLED
- Wattage: 150W
- Type III or Type V Lighting Distribution
- Voltage: 120-277V
- Lumens: 21,000Lm
- CCT: 4000K or 5000K
- 1-10V dimming
- Listings: UL Listed for Wet Locations and DLC Premium
- 5 year warranty
- Brand: LEDSION
- Wattage: 300W
- Lumens: 39,000
- CCT: 5000K
- Voltage: 100-277V
- CRI: >70
- 0-10V dimmable
- Life: 50,000 hours
- Low profile housing with enhanced thermal heat sink
- 6kV built-in plus 10kV external surge protection
- Mounting Bracket Included
- DLC# LS-ESBV7E300WAT3A1
- Listings: cULus, DLC Premium
- 5 year warranty
- Brand: LEDSION
- Wattage: 150
- Voltage: 100-277
- Lumens: 21000
- CCT: 5000K
- CRI: >70
- 0-10V dimmable
- Life: 50,000 hours
- Listings: UL, IP65, DLC
- DLC# LS-ESBV7E150WAT3A1
- 5 year warranty
- Mounting Bracket Included
- Brand: GKOLED
- Wattage: 300W
- Type III or Type V Lighting Distribution
- Voltage: 120-277V
- Lumens: 42,000Lm
- CCT: 4000K or 5000K
- 1-10V dimming
- Listings: UL Listed for Wet Locations and DLC Premium
- 5 year warranty
- Brand: WSD
- Wattage: 400W
- Voltage: 277-480
- Lumens: 56,783Lm
- CCT: 5000K
- CRI: >70
- Lifespan: Over 50,000hrs
- Dimensions: L 25.53" x W 14.57" x H 3.16"
- 0-10V dimmable
- Listings: UL, IP65, DLC Premium, RoHS, FCC
- 5 year warranty
- Brand: WSD
- DLC Partner: Wisdom
- ID#: PMC2TP6T
- Wattage: 150
- Voltage: 277-480
- Lumens: 21000
- CCT: 5000K
- CRI: >70
- Dimensions: L 24" x W 11.13" x H 6.3"
- Net Weight: 13.2 lbs
- 0-10V dimmable
- Life: 50,000 hours
- Listings: cULus, IP66, DLC Premium
- 5 year warranty
- Bronze Finish
- Brand: WSD
- DLC Partner: Wisdom
- ID#: P330V1EJ
- Wattage: 300
- Voltage: 277-480
- Lumens: 40121
- CCT: 5000K
- CRI: >70
- Dimensions: L 25" x W 19" x H 3.16"
- Net Weight: 25.4 lbs
- 0-10V dimmable
- Life: 50,000 hours
- Listings: cULus, IP66, DLC Premium
- 5 year warranty
- Bronze Finish
- Brand: WSD
- DLC Partner: Wisdom
- DLC ID#: PXC0X1HG
- Wattage: 60
- Voltage: 120-277
- Lumens: 8700
- CCT: 5000K
- CRI: >70
- Dimensions: L 23.8" x W 11.13" x H 6.3"
- Net Weight: 9.9 lbs
- 0-10V dimmable
- Life: 50,000 hours
- Listings: cULus, IP66, DLC Premium
- 5 year warranty
- Bronze Finish
- Brand: WareLight Select
- Wattage Selectable: 120W/180W/240W/300W
- Voltage: 120-277V
- Lumens: 19,200Lm-45,000Lm (See spec for details)
- CCT Selectable: 3000K/4000K/5000K
- Dimming: 0-10V
- Mounting Options: Square Pole Mount and Slipfitter
- CRI:>70
- Operating Temperatures: -40˚C to 40˚C (-40˚F to 104˚F ).
- Ratings: UL, Wet Locations
- 5 year warranty
- Brand: WSD
- DLC Partner: Wisdom
- ID#: PNQ1SUKD
- Wattage: 200
- Voltage: 277-480
- Lumens: 27000
- CCT: 5000K
- CRI: >70
- Dimensions: L 24" x W 11.13" x H 6.3"
- Net Weight: 16.6 lbs
- 0-10V dimmable
- Life: 50,000 hours
- Listings: cULus, IP66, DLC Premium
- 5 year warranty
- Bronze Finish
- Brand: GKOLED
- Wattage: 100W
- Type III or Type V Lighting Distribution
- Voltage: 120-277V
- Lumens: 14,100-14,200
- CCT: 4000K or 5000K
- 1-10V dimming
- Listings: UL Listed for Wet Locations and DLC Premium
- 5 year warranty
- Brand: Etherium
- Wattage Selectable: 100W/150W/200W
- CCT Selectable: 3000K/4000K/5000K
- Lumens: 14000/21000/28000LM
- Voltage: 120V-277V
- CRI: 80
- Life: 75,000 hrs
- Dimmable: 0-10V
- Operating Temperature: -4°F to 113°F (-20°C to 45°C)
- Anti-UV Frosted Polycarbonate Lens standard.
- Call for Glare Shield Availability
- Ratings: DLC Premium listed, cULus Listed, Wet Location
- Warranty: 5 years
- Brand: WSD
- Wattage: 300W
- CCT: 4000K or 5000K
- Lumens: 42132 LM
- Voltage: 120-277V
- CRI: 70
- Optic: Type III
- Finish: Dark Bronze
- Life: 50000 hours
- Listings: UL Listed, DLC Premium, Wet Location, ROHS
- 5 year warranty
- Brand: WareLight Select
- Wattage Selectable: 60W/90W/120W/140W
- Voltage: 120-277V
- Lumens: 9,700Lm-23,000Lm (See spec for details)
- CCT Selectable: 3000K/4000K/5000K
- Dimming: 0-10V
- Mounting Options: Square Pole Mount, Slip Fitter
- CRI:>70
- Operating Temperatures: -40˚C to 40˚C (-40˚F to 104˚F ).
- Ratings: UL, Wet Locations
- 5 year warranty
- Brand: Etherium
- Wattage Selectable: 100W/150W/200W
- CCT Selectable: 3000K/4000K/5000K
- Lumens: 14000/21000/28000 LM
- Voltage: 347-480V
- CRI: 80
- Life: 75,000 hrs
- Dimmable: 0-10V
- Operating Temperature: -4°F to 113°F (-20°C to 45°C)
- Anti-UV Frosted Polycarbonate Lens standard.
- Ratings: DLC Premium listed, cULus Listed, Wet Location
- Warranty: 5 years
- Brand: Etherium
- Wattage Selectable: 200W/240W/300W
- CCT Selectable: 3000K/4000K/5000K
- Lumens: 28000/33600/42000LM
- Voltage: 347-480V
- CRI: 80
- Life: 75,000 hrs
- Dimmable: 0-10V
- Operating Temperature: -4°F to 113°F (-20°C to 45°C)
- Anti-UV Frosted Polycarbonate Lens standard.
- Ratings: DLC Premium listed, cULus Listed, Wet Location
- Warranty: 5 years
- Brand: Etherium
- Wattage Selectable: 200W/240W/300W
- CCT Selectable: 3000K/4000K/5000K
- Lumens: 28000/33600/42000LM
- Voltage: 120V-277V
- CRI: 80
- Life: 75,000 hrs
- Dimmable: 0-10V
- Operating Temperature: -4°F to 113°F (-20°C to 45°C)
- Anti-UV Frosted Polycarbonate Lens standard.
- Ratings: DLC Premium listed, cULus Listed, Wet Location
- Warranty: 5 years
- Brand: Keystone Technologies
- Wattage Selectable: 140W/100W/70W
- CCT Selectable: 3000K/4000K/5000K
- Lumen Max: 20780
- Voltage: 120-277V
- CRI: >80
- Life: 100,000 hours
- Keystone 0-10V dimming driver
- Ambient operating temperature: −40°C/−40°F to 50°C/122F
- Listings: UL Certified, IP65 rated, DLC Premium, ROHS
- Warranty: 5 Years
- Brand: WSD
- Wattage Selectable: 120W/180W/240W/300W
- CCT Selectable: 4000K/5000K
- Lumens: 44031 LM
- Voltage: 277-480V
- CRI: 70
- Optic: Type III
- Finish: Dark Bronze
- Life: 75000 hours
- 1-10V dimming (10%-100%) standard
- Listings: UL Listed, DLC Premium
- 5 years warranty
- Brand: WSD
- Wattage Selectable: 120W/180W/240W/300W
- CCT Selectable: 4000K/5000K
- Lumens: 44714 LM
- Voltage: 120-277V
- CRI: 70
- Optic: Type III
- Finish: Dark Bronze
- Life: 75000 hours
- 1-10V dimming (10%-100%) standard
- Listings: UL Listed, DLC Premium
- 5 year warranty
LED Bridge Lighting Fixtures
Please call us for more information on Bridge Office Lighting.
